iBase SI-654-N 8K UHD Digital Signage Player
The iBase SI-654-N 8K UHD Digital Signage Player wins in all four corners: Power, Size, Industrial Strength, and Fanless Design
With this new compact and rugged solution, the iBase extensive portfolio of Digital Signage players has leaped into the 8K signage space. Mainly designed for digital signage in busy places where there is a constant demand for practical information, the SI-654-N fanless 8K UHD digital signage player features HDMI-CEC control, display status monitoring, flexible video wall configurations and hardware EDID emulation that prevents distorted or black screens due to display and cable connection issues. It is ideally suited for video wall solutions in airports, shopping malls, and other commercial premises that require reliable 24/7 operation. With iBASE advanced iSMART and Observer technologies, the digital signage player hardware is equipped with low-temperature boot protection, power resume control, power on/off scheduling, and hardware monitoring to enable continuous and stable operation of the system.
Need unique configurations or customized hardware or BIOS? Just ask!
These are just part of what separates iBase and Macnica from the competition.
Specifications
| System Mainboard | MBD654 |
| CPU | 11th Gen Intel® Core™ / Celeron® U-series (TGL-U Platform) processor TDP<=15W |
| CPU Socket | BGA-1449 |
| Chipset | Integrated |
| Memory | 2x DDR4-3200 SO-DIMM, Max. 64GB |
| Graphics | 11th Gen Intel® Core™ U-series Gen12 integrated graphics, Up to 96EU |
| LAN | 1st LAN SI-654-N7 or SI-654-N5 : Intel® I219LM SI-654-N3 : Intel® I219V 2nd LAN Intel® I211AT |
| Expansion Slots | 1x M.2 2280 M-key supports NMVe (PCI-E x4 / SATA) 1x M.2 2230 E-key supports CNVi (PCI-E x1 / USB 2.0) 1x M.2 3042 B-key (PCI-E x2, USB 2.0 and 3.0) 1x UIM/SIM card slot |
| I/O Interface | 4x HDMI 2.0 1x USB 2.0 (USB A-Type) 3x USB 3.1 @gen 2 (USB A-Type) 2x RJ45 for Gigabit LAN 1x RJ45 for RS232 serial port 1x Audio connector for Line out 1x Power button 1x Power jack (+12V DC) 2x LED for power & storage |
| Auto Control and Monitoring | Watchdog Timer: 256 segments, 0, 1, 2…255 (sec/min) |
| Power Requirement | +12V DC |
| Construction | Aluminum + SGCC |
| Weight | 1.7 kgs (3.7 lbs) |
| Chassis Color | Black & White |
| Storage | 1x M.2 2280 M-key supports NMVe (PCI-E x4 / SATA) |
| Power Supply | 84W power adaptor |
| Mounting | Standard system bracket |
| Dimensions | 200.8mm(W) x 139.3mm(D) x 41.2mm(H) 7.90”(W) x 5.48”(D) x 1.62”(H) |
| Operating Temperature | 0°C~ 45°C (32°F~113°F) |
| Storage Temperature | -20° ~ 80°C (-4°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Vibration | M.2: 5 grms / 5~500Hz / random operation |
| Certification | CE, FCC Class B, cULus & CCC |
Ordering Information
| SI-654-N7 | Intel® Core™ I7-1185G7E Processor (12M Cache, up to 4.40 GHz), 2x 4GB DDR4 3200 SO-DIMM memory, M.2 128GB and 84W power adaptor, TDP<=15W |
| SI-654-N5 | Intel® Core™ I5-1145G7E Processor (12M Cache, up to 4.40 GHz), 2x 4GB DDR4 3200 SO-DIMM memory, M.2 128GB and 84W power adaptor, TDP<=15W |
| SI-654-N3 | Intel® Core™ I3-1115G4E Processor (12M Cache, up to 4.40 GHz), 2x 4GB DDR4 3200 SO-DIMM memory, M.2 128GB and 84W power adaptor, TDP<=15W |
| SI-MK3 | VESA bracket |
About iBase Technology
iBase Technology is known for:
- A 20-year history of producing a wide portfolio of robust industrial embedded computing solutions
- Digital signage industry leadership
- SBC’s, industry-standard modules, packaged solutions, ISO certified quality offerings
- Wide variety of platform performance, cost, features, and partners: Intel, AMD, NXP (ARM)
- High-performance edge computing solutions
- Flexibility with cost-effective customization options
